Low Voltage MOSFET
KU016N06CS1
NEW
Split Gate Trench MOSFETs, PDFN56(1),60V, 234A
Application
· DC/DC Converter, Synchronous
· Rectification, Motor control, switching circuits
Features
· VDSS=60V, ID=234A
· Drain-Source ON Resistance:
RDS(ON)(Max)=1.6mΩ @ VGS=10V
· Qg(typ.)=96nC @ VGS=10V
· Tj=175℃
| Item No | KU016N06CS1 |
|---|---|
| Status | NEW |
| AEC-Q | N |
| Package | PDFN56(1) |
| Polarity | N |
| BVDSS[V] | 60 |
| ID[A] | 234 |
| PD[W] | 167 |
| RDS(ON)@10V[Ω] | 0.0016 |
| Qg [nC] | 96 |
| Vth_MIN[V] | 2.1 |
| Vth_MAX[V] | 3.3 |
| Ciss[pF] | 6223 |
| ESD DIODE | N |
Product Datasheet
-
[Product Datasheet] KU016N06CS1_R0.pdf
657.8 KBPDF
-
[Marking Information] M KU016N06CS1_R0.pdf
392.2 KBPDF
-
[Package Dimension] PDFN56(1) PKG_R1.pdf
89.9 KBPDF
-
[Packing Information] PDFN56(1) Packing_R0.pdf
3.1 MBPDF
-
[Recommended Pad Dimension] PDFN56(1)_RPD_R0.pdf
642.4 KBPDF
